XINSHENG makes connectors for high-frequency communication. Our products
send signals reliably and always stay stable. We have high-frequency RF connectors, as well as high-speed electrical
and hybrid connectors. We can make products in our own factory and build cable assemblies.
Our connectors are used in 5G networks, defense, electronics, cars, and factories. We always test our products before sending them out. We also make parts that match global brand products. They work the same as the original parts.
Our high-frequency connectors work across many frequencies. They keep signals stable and reliable. Suitable from 3 GHz to 110 GHz.
XINSHENG connectors are made with a precise design. This ensures accurate performance and very low signal loss, with tolerances up to ±0.001 mm.
These high-frequency connectors are strong and long-lasting. They resist vibration, heat, water, salt, and rough use. Tested with IP67, salt spray, and tensile tests.
XINSHENG connectors allow fast and smooth data transfer. Perfect for electronics, communication systems, and 5G applications.
Our connectors manage heat well. They stay stable and work safely even in high temperatures up to 200 °C.
We can make high-frequency connectors and cable assemblies to fit your needs. Special designs and unique applications are available.
XINSHENG offers a comprehensive range of high-frequency connectors:
high frequency data transmission connector, base station interconnects
Defense high-frequency communication service, radar systems, avionics
ADAS, V2X communication, and autonomous vehicle sensors
Power amplifiers, control box, high frequency radio communication device, AUX, AUDIO, Data transmission box
Signal analyzer, oscilloscopes, network analyzers, and calibration/test equipment
Industrial robots, sensor networks and high-speed data
| Parameter | Standard Performance | Premium Performance |
|---|---|---|
| Frequency Range | DC to 18 GHz | DC to 110 GHz |
| VSWR | ≤1.50:1 or ≤2:1 | ≤1.2:1 |
| Insertion Loss | ~ 0.15-0.25 dB to 0.8-1.2 dB @ 3-110GHz | ~ 0.05-0.15 dB to ~0.3-0.6 dB @ 3-110GHz |
| Impedance | 50Ω or 75Ω | 50Ω, 75Ω, or custom |
| Durability | 500 mating cycles | 1000+ mating cycles |
| Operating Temperature | -40°C to +85°C | -55°C to +200°C |
Our engineering team is ready to help you select or design the perfect high-frequency solution for your application.
